ORIGIN LIVE BRAS DE LECTURE SPECIFICATIONS
 Premium Tonearm Range
| Illustrious | Encounter | Silver | Effective Length 9′ (mm)
| 237 | 237 | 237 | Effective Length 12′ (mm)
| 309 | 309 | 309 | | Overhang 9′ | 17.24 | 17.24 | 17.24 | Overhang 12′
| 13.2 | 13.2 | 13.2 | Offset Angle 9′ (°)
| 22 | 22 | 22 | Offset Angle 12′ (°)
| 17.6 | 17.6 | 17.6 | Distance from Pivot to Spindle 9′ (mm)
| 222 | 222 | 222 | Distance from Pivot to Spindle 12′ (mm)
| 295.6 | 295.6 | 295.6 | Diamiter for Mounting Hole (mm)
| 23-24 | 23-24 | 23-24 | Size of Base Mounting Nut (across flats, mm)
| 32mm A/F | 32mm A/F | 32mm A/F | Maximum Armboard Thickness (mm)
| 27 | 27 | 27 | External Arm Cable Length
| 1.2, DJ option 2 | 1.2, DJ option 2 | 1.2, DJ option 2 | | Capacitance and Resistance | 130 pF & 0.0017 ohm per channel | 130 pF & 0.0017 ohm per channel | 130 pF & 0.0017 ohm per channel | | Capacitance and Resistance for Silver Hybrid/S Cable | 65pF & 0.05 ohms per channel | 65pF & 0.05 ohms per channel | 65pF & 0.05 ohms per channel | Effective Mass 9′ (g)
| 12.7 | 12.5 | 12.0 | | Effective Mass 12′ (g) | 16.875 | 16.2 | 16.2 | | Weight 9′ (g) | 850 | 654 | 570 | Weight 12′ (g)
| 900 | 620 | 620 | Shipping Weight (g)
| 1850 | 1734 | 8(0 | | Stylus Force Gauge Included | Yes | No | No | | Inbuilt Threaded VTA Adjuster | No | Yes | No |
|
